Sniff It Non Contact AC Voltage Detector - (9602)

Name: Sniff It Non Contact AC Voltage Detector - (9602)
Brand: Triplett
SKU: 9602
Price: 18.69 USD
Availability: OutOfStock

by Triplett

SKU 9602

6 14395 03094 0

Out of Stock

$18.69 - $18.69

$18.69

$18.69 - $18.69

$18.69

Extended Lead Time: Up to 11 business days for NIST Calibration

Quantity

Description

The Triplett Sniff-It 2 is a high performance non-contact AC Voltage detector with adjustable sensitivity.
It provides a wide measurement range of 5 to 600 Volts AC.
The high sensitivity allows it to detect low voltage AC wiring commonly found in doorbell circuits, thermostats, control circuits, and video surveillance camera power.
The ABS plastic housing provides impact and drop resistance in a sleek ergonomic design.
Includes pocket clip and A23 battery.
5 year warranty.

Features

Detects AC Voltage from 30 to 600 volts without making contact
On/Off switch with power on indicator (green LED)
Light flashes (red LED) and beeper chirps when AC voltage is present and flashes and beeps faster as AC voltage is approached
CAT IV 600V safety rating, includes (2) AAA batteries and 5 year warranty

Specifications

Voltage Range	30 to 600VAC
Frequency Bandwidth	60Hz
Sensitivity	Fixed
Indicators	audible and visual (blinking red LED)
On/Off switch	Yes with green LED power on indicator
Power	(2) AAA batteries
Dimensions	6.25 x 0.5 x 1" (158 x 12.7 x 25.4mm)
Weight	1.6oz (45.4g)

Manual

Product Information
